ACT XT-O/Race Sprung 6 Pad Kit

        ACT XT-O/Race Sprung 6 Pad Kit

        Part Number:T43-XTG6
        Advanced Clutch
        T43-XTG6 kit features ACT's powerful Xtreme pressure plate and spring center 4 pad race disc delivering ultra-high torque capacity, aggressive engagement, quiet operation and increased toughness to withstand the demands of off-road racing. ACT’s exclusive diaphragm design dramatically increases clamp load, reduces deflection and maximizes clutch life. All diaphragms endure a four-stage heat-treating process for unparalleled performance. ACT precision pressure plate cover stampings provide rigidity and consistency while precision machined pressure plate castings absorb heat. ACT’s spring center 4 pad race discs boast quality parts throughout, with robust spring center sections to absorb driveline shock and premium ceramic friction materials to hold power even under the most abusive conditions.
        • "Excellence in Performance", backed by the best one-year warranty in the industry!
        Retail price
        • $774.00
        Features
        • SKU
          T43-XTG6
        • Brand
          Advanced Clutch
        • Clutch Disc Diameter
          236 mm
        • Clutch Disc Diameter
          9.30 in.
        • Clutch Master Cylinder Included
          No
        • Clutch Slave Cylinder Included
          No
        • Disc Material
          Ceramic
        • Disc Type Sprung Solid
          Sprung
        • Flywheel Bolts Included
          No
        • Grade Type
          Performance
        • Grease Included
          Yes
        • Includes Alignment Tool
          Yes
        • Includes Release Bearing
          Yes
        • Input Shaft Diameter
          1.125 in.
        • Input Spline Quantity
          21
        • Pilot Bearing Included
          Yes
        • Pilot Bushing Included
          No
        • Pressure Plate Bolts Included
          No
        • Pressure Plate Series
          Xtreme
        • Prop 65 - Required to list in California with Warning
          Yes
        • Prop 65 - Short Label
          WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
        • Prop 65 Long Label
          Warning: This product can expose you to chemicals including carbon black, glass wool fibers, or silica (in clutch discs), chromium and nickel, which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65Warnings.ca.gov
        • Torque Capacity
          450 ft/lbs.
        • Torque Capacity Percentage Over Stock
          107%
        • Weight
          17.3 lbs. (7.8 kg)
