Automatic Transmission Assembly 1064194BM
Part Number:1064194BM
When you purchase a BD transmission and torque converter package, you are getting a matched set that has been dyno tested together for ultimate performance, and reliability. Every transmission comes with BD's own Heavy Duty pan that adds extra fluid capacity. For towing, street or track, when it comes to a dependable transmission that will stand up to your diesel's power and torque demands, the clear choice is BD.
- TRANSMISSION:
- Our goal is to be an innovative company and a world class manufacturer that distributes products Worldwide for North American Diesel vehicles.
- Our goal is to be an innovative company and a world class manufacturer that distributes products Worldwide for North American Diesel vehicles.
- Stock thrust bushings replaced with roller Torrington bearings
- Triple Disc
- Enhanced Stall - Street/Towing applications
- HD springs absorb shock of engagement
- Stamp forged 1-piece cover
- Eliminates warpage from clutch heat
- Taller cover can be rebuilt more often
- Trapezoid teeth design
- Engineered tighter tolerances
- Self-centering trapezoid teeth design increases contact decreases wear and chatter
- Thrust bearings - not plastic thrust washers
- Riveted piston ensures alignment & eliminates vibration or embrittlement from welding
- Cast stator designs maximizes torque
- New sprag components ensure long term durability
- Furnaced brazed turbine fins for improved fluid coupling efficiency
- Reduced overall weight by 12lbs compared to competitors
- Clutch Count: DIRECT 6
- Clutch Count: FORWARD 5
- Clutch Count: OD 6
- Clutch Count: OD DIRECT 10
- High temp/energy Raybestos band
- Upgraded Valvebody
- Billet band lever
- Billet band strut
- Billet Input Shaft to take the "snap" from rapid throttle and high horsepower
- Billet "Big" fine spline input shaft
- Upgraded governor solenoid
- Drilled intermediate shaft for increased lubrication
- Upgraded governor pressure transducer (47RE/48RE) - Twice the burst pressure than stock
- Increased line pressure to 190-200psi
- No shuttle shifting problems
- BD rigid aluminum heavy duty transmission pan
- Pan adds 2qt extra oil capacity
- Pan heat-dissipating fins keep temperature down
- Magnetic
